125-2

2 x 250W PA Amplifier

Available Barcode : 8015439012526
Product By: Brand
Designed for piped systems, it is able to provide an RMS power of 2x125W with both 4 Ohm and 70V/100V output.
Each channel has independent balanced XLR input and independent volume control.
A selector allows you to choose the mode of use between MONO and DUAL. A filter can be operated for cutting high/low.
Each channel has independent LED indicators for signal, 4 Ohm, 70V, 100V and Pro.


Features:

• Output 4 OHM/70V/100V without output transformer.
• Choose 4OHM /70V/100V output by switch
• Each channel has separate balanced input (XLR)
• Each channel has separate volume control
• Choose MONO or DUAL output by switch
• Choose full range output or L/H CUT
• Each channel has separate indicator for SIG. 4O. 70V. 100V. PRO
• Temperature protection/overload protection/DC protection
Features:
Matrix No
Max power 500
RMS power 2 x 125W
4 Ohm max power 500 W
8 Ohm max power 250W
Input impedance 70V, 100V
Impedance 4 Ohms
Multi zone No
Phantom Key No
Cooling fan 1 fan
Rack space 2U
Input connectors XLR
Output connectors screw terminal
Line inputs 2
Mic inputs 0
Constant voltage 70 - 100V compatible
S/N ratio >95dB
Frequency response L/H cut off 20Hz - 20 KHz
Color black
Weight 6,9
Product dimensions 435 x 88 x 340mm
GUIDA PA SYSTEM Download
Instruction manual Download
Manuale italiano Download
