PAA 660TMZ

6 zone 360W PA amplifier

Available Barcode : 8015439206604
Product By: Brand
One of the most evolved PA amplifiers on the market. It can manage 6 matrix zones and it can receive an input signal and send it independently to one of the 6 outputs. Each zone is endowed with a separate volume and keys for immediate exclusion. It includes a MP3 module with display, radio am/fm and USB/SD sockets. Priority function on the microphone and headphone connector with adjustable volume.
It can support 8 Ohms or 70/100V connections.


Features:
Matrix Yes
Max power 360
RMS power 180 W
Multizone 6 zones
8 Ohm max power 6 x 60W
Impedance 8 Ohms
VU METERS Yes
Phantom Key Yes, it allows to enable phantom power for condenser microphones
Multi zone Yes
REC function No
Mp3 player Yes
MP3 compatible Yes
CD/ USB USB and SD
Siren & Whistle Siren
Rack space 2U
Output connectors Terminals
Input connectors XLR + jack 6,3mm
Mic inputs 3
Line inputs 4
Constant voltage 70 - 100V compatible
S/N ratio >60 dB
Frequency response 80Hz- 16 KHz
Notes 6 zones with independent volume
Color Black
Weight 11,4
Product dimensions 420 x 340 x 89 mm
Power supply 110V - 220V
Dichiarazione di conformitą RED Download
Dichiarazione RoHS Download
GUIDA PA SYSTEM Download
Info collegamenti Download
Manuale Download
