PAA 120M2Z

120W 2-zone amplifier

Available Barcode : 8015439241209
Product By: Brand
PA amplifier suitable for 70/100V or low impedance operation. 100V signals can also be managed thanks to its 2 zones. It is possible to connect up to 3 microphones and 4 line signals, each with independent volume control. Phantom power and priority function can be activated on microphone 1. It is equipped with terminals for a monitor speaker and sockets for 24V power supply. The multimedia module can play MP3 songs from microSD, USB, bluetooth. It is also endowed with FM radio.
The maximum power is 120W.



Features:
MP3 compatible Yes
Input connectors XLR + RCA + Jack 6,3mm
Output connectors terminals + RCA
Line inputs 4
Mic inputs 3
Impedance 4 - 8 - 16 Ohms
Constant voltage 70 - 100V compatible
Multi zone 2 zones
S/N ratio Line >85dB, Mic > 72dB
Frequency response 60 Hz - 15 Khz (+/-3dB)
Voice priority function Yes, on MIC 1 only
VU METERS Yes
Phantom Key Yes
RMS power 60
Multizone 2 zones
Mp3 player Yes
Tel paging function Yes
Matrix No
Max power 120
DC Power 24V
Bluetooth yes
Color Black
Weight 4,2 kg
Product dimensions 320 x 210 x 90 mm
Power supply 220V - 24V
Dichiarazione di conformitą Download
Manual Download
