CSL 620

20W in-ceiling speaker with transformer

Available Barcode : 8015439906207
Product By: Brand
In-celing white speaker for constant-voltage systems with 6,5" woofer. It stands out for its extremely low thickness (66 mm only). Endowed with transformer, it can be set on two different powers: 5W and 10W (RMS). It is suitable to be installed in any kind of location thanks to its elegant white colour.


Features:
Max power 20
Sensitivity 92 db
Frequency response 130 - 15000 Hz
Impedance 8 Ohms
Transformer Internal trasformer for 100V use
Woofer dimension 6,5" (16,3cm)
Mount hole diameter 165mm
RMS power 10W
Opearting voltage 100V
Material Plastic (ABS)
Mounting bracket Yes
Kind of speaker Passive
Color White
Weight 0,5
Product dimensions 185 x 185 x 66mm
Notes Mount hole diameter: 165mm
